AUGX12 Standard Type 3 Pin Male Plug Solder
Código: AUGX12-B-3-P
R$ 1,35
Consulte disponibilidade
Informações do Produto
| Part Number / Código | AUGX12-B-3-P |
|---|---|
| Categoria | Conectores circulares |
Descrição
AUGX12 Standard Type 3 Pin Male Plug Solder
Especificações Técnicas
| model | AUGX12‑B‑3‑P |
|---|---|
| gender | Male |
| series | AUGX12 |
| produto | AUGX12 Standard Type 3 Pin Male Plug Solder |
| temp_max | +85 °C °C |
| temp_min | −20 °C °C |
| ip_rating | IP40 (up to IP55 with proper panel sealing) |
| application | Panel |
| description | AUGX12 Standard Type 3 Pin Male Plug Panel Mount Solder |
| connector_type | Circular metálico |
| contact_finish | Silver-plated |
| fastening_type | Rear nut (Panel Mount) |
| mounting_style | Panel (Wire Solder) |
| shell_material | Nickel-plated zinc alloy |
| voltage_rating | 125 V AC / DC V |
| coupling_system | Threaded |
| mechanical_life | ≥ 500 cycles cycles |
| contact_material | Copper |
| approximate_weight | 12 g |
| contact_resistance | ≤ 10 mΩ mΩ |
| number_of_contacts | 3 |
| contact_termination | Solder Cup |
| categoria_de_produto | Conectores circulares |
| insulating_materials | Bakelite / phenolic plastic |
| insulation_resistance | ≥ 1000 MΩ @ 500 VDC MΩ |
| dielectric_withstanding_voltage | 1000 VAC / 1 min VAC |
